Mini Groundnut Peanut Copra Corn Mustard Seed Soya Soybean Sunflower Small Coconut Palm Kernel Oil Mill Machine
- Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Home Use
- Showroom Location:
-
Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Kenya, Argentina, South Korea, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Nigeria, Uzbekistan, Tajikistan, Japan, Malaysia, Australia
- Condition:
-
New
- Usage:
-
coconut palm kernel
- Type:
-
Cold & Hot Pressing Machine
- Automatic Grade:
-
Automatic
- Production Capacity:
-
98%-100%
- Place of Origin:
-
Henan, China
- Brand Name:
-
Hongde small oil mill machine
- Voltage:
-
380V, 50HZ, 3Phase
- Dimension(L*W*H):
-
1860*670*1680 1060*590*600mm
- Weight:
-
780 KG
- Warranty:
-
1 Year
- Key Selling Points:
-
Automatic
- Marketing Type:
-
Other
- Machinery Test Report:
-
Provided
- Video outgoing-inspection:
-
Provided
- Warranty of core components:
-
1 Year
- Core Components:
-
Other
- Oil type:
-
sunflower seed oil, Coconut Oil
- Max Capacity:
-
150 kg/h
- After-sales Service Provided:
-
Engineers available to service machinery overseas
- Year of Manufacture:
-
2018
- Color:
-
Optional
- Delivery time:
-
30 days
- Function:
-
Oil Press + Drum Filter
- Capacity:
-
3~4 T/D mini oil mill machine
- Machinery type:
-
small screw palm kerne oil mill machine
- Advantage:
-
Energy Saving small coconut oil mill machinery
- Raw material:
-
coconut palm kernel sunflower peanut cottonseeds rapeseeds
- Application:
-
Small oil mill plant
Mini groundnut peanut copra corn mustard seed soya soybean sunflower small coconut palm kernel oil mill machine
What’s small oil mill machine?
YZS-80A small oil mill machine is one of the most efficient cold oil press machine developed newly. The main structure of this mini oil mill machine includes a motor, two vacuum filters, a heater and an electric control cabinet. With advanced automatic oil-cleaning and temperature rising system, YZS-80A small oil mill machine is able to serve as a cold oil mill machine and a hot oil mill machine, which will greatly expand the scope of pressed seeds. Generally, it can process soybeans, peanuts, palm kernel, sesame seeds, moringa seeds, jatropa, mustard seeds, sunflower seeds and more!
Key technical data of small oil mill machine
| Model | Capacity(T/24H) | Power(KW) | Dimensions(MM) | Weight(KG) |
| YZS-68A | 1 | 5.5 | 940*570*1170 | 260 |
| YZS-80A | 3-4 | 5.5+0.75 | 1860*670*1680 1060*590*600 |
780 |
| YZS-90A | 3-4 | 5.5+0.75 | 1860*670*1680 1060*590*600 |
780 |
| YZS-95A | 5 | 7.5+1.5 | 2250*890*1820 1230*640*570 |
900 |
| YZS-100A | 5 | 7.5+1.5 | 2270*750*1820 1220*590*600 |
900 |
| YZS-120A | 6 | 15+1.1 | 2280*890*1775 1350*700*600 |
1000 |
| YZS-130A | 10 | 18.5+1.5 | 2350*810*2000 1350*700*570 |
1000 |
Note: All the YZS Series integrated oil mill machine is certificated with ISO9001:2015 and CE. So there are no worries on its quality!
Main structure of small coconut oil mill machinery
Typically, the small coconut oil mill machinery is composed of four main parts, the feeder, the press cage, the cabinet control box and the vacuum filters. Every part works to extract oil efficiently and smoothly.
What’s the operating principle of small coconut oil mill machinery?
When the small coconut oil mill machinery runs, the processed oil materials enter into the squeezing chamber through the hopper. The screw rotor propels the oil materials inward and squeeze them. The oil materials in the squeezing chamber is motorial. In the high-pressure chamber, there is great friction resistance between oil materials and squeezing spiral or squeezing chamber, thus the micro materials can create friction.
On the other hand, the squeezing screw diameter is gradually thickening and the screw pitch is gradually decreasing, so when the squeezing screw rotates, the screw threads can propel the oil materials forward or outward. The heat generated by friction can improve the yield of the oil press, and let the oil flows from the gaps. When the overflowing oil flows onto the oil filtering barrel through the oil tray, the vacuum pump pumps the air in the barrel, and then negative pressure forms in the barrel. The oil is pumped into the barrel through the filtering cloth and the oil residues are left on the filtering cloth.
Hongde palm kernel oil mill machine for sales
Hongde small palm kernel oil mill machine is one of the most popular oil processing machinery in Africa and Asia. Its high quality, low price and stable performance make it BEST choice for many small scale oil mill plants!
Other materials suitable for palm kernel oil mill machine
YZS-80A palm kernel oil mill machine can process a very wide range of raw materials, including mustarde seeds, corn germ, sunflower seeds, copra, moringa seeds, tea seeds and more. If you can’t find your materials in the above picture, please contact us to check your materials for the palm kernel oil mill machine!
Hongde built oil mill plant projects
Hongde is your reliable oil mill machine supplier, including small coconut oil mill machinery, palm kernel oil mill machine and more. In addition, we have built many large scale oil mill plant worldwide. If you want to know more information about the projects information, please contact us directly!
Mini oil mill plant with oil mill machine
High quality spare parts of oil mil machine
The small palm kernel oil mill machine spares and accessories are necessary to carry out the trouble free operation of oil mill machine and prevent the sudden stoppage of oil mill machinery line. We provide a whole lot of spares and accessories along with our oil mill machine for the customer’s convenience. The complete set of oil mill machine spares and oil mill machine accessories ensure that the optimum machine working is achieved.
Our extra spares parts of oil mill machine also reduce the machinery downtime. During the breakdown or maintenance, the oil mill machine operator can easily change and replace the old part with the supplied new part. This will lead to trouble-free working of the oil mill machine. as for our every set of oil mill machine, the extra set of accessories and spares is provided. The below picture depicts few of the items which are supplied as the spares and accessories.
