200tpd Turnkey Processing Extraction Peanut Oil Make Production Plant

200tpd Turnkey Processing Extraction Peanut Oil Make Production Plant is a kind of oil press equipment with the automatic temperature control function, which is widely used in different edible oil processing plants. Automatic temperature controlled oil press machine uses an electric heating coil device to heat the press, and make the oil press machine pre-heated quickly and start the production quickly. It can be used for various raw materials, such as soybeans, peanuts, cotton seeds, rape seeds, sesame seeds, sunflower seeds, canola seeds, coconut seeds, tea seeds, palm seeds and jatropha seeds.

SEND INQUIRY NOW

Advantages of Hongde Grain And Oil Machinery Co., Ltd. peanut oil making machine:

(1) Secondary press minimizes residual oil in the cake.

(2) Automated factories make production more efficient.

(3) Continuous production, give full play to the function of the machine.

(4) One-stop service, directly provide all the needs.

(5) Low unit production cost, low labor consumption.

(6) Oil products are of high quality and of high value in the international market.

Peanut Pretreatment process:

1) Cleaning: Our vibration screen and destoner will remove various impurities from raw material peanut such as: irons, stones, clumps, after clean up the peanut impurity content lower than 0.2%. This will ensure that they can follow the normal operation of the press process. This step is to improve the quality of the whole peanut.Easy storage, no odorous gas lift.

2) Crushing: Oil seeds is crushed into 6-8 pieces. The purpose of this section is to relieve the pressure on the embryo pressing section.Reduce powder production.

3) Flaking: Rolling raw material into flakes, and the purpose is to destroy the peanut cell tissue, and increase contact surface area. It’s much easier to be heated or to adjust to different states of moisture.

4) Cooking: The purpose of cooking is to adjust the moisture and temperature of oil seeds, this destroys the cell walls of the oil and provides the conditions for subsequent embryo pressing.

5) Pre-press: Press the flakes to suitable oil content of 15%-16% in the cake.This is to reduce the pressure of the secondary press.To extract as much residual oil as possible.

6) Second oil pressing: cake will extracted again with oil residue content about 5%. This part of the oil mill is specially designed to minimize residue at a slower rate.

7) Filter:Filter the oil for impurities.To improve the whole quality.Reduce the pressure of refining.

Advantages of Hongde Grain And Oil Machinery Co., Ltd. peanut oil making machine:

1. Special cold refining technology is necessary for fragrant peanut oil, fragrant rapeseed oil, fragrant sesame oil and fragrant linseed oil. It can remain the original aroma and meet the national standards at the same time.

2. Cold refining process equipment, which is very popular with the customers, researched by OCEAN meets the demand of traditional and modern technology standards.

Refining process of peanut oil making machine:

(1) Degumming and Neutralization: The non-hydrophilic phospholipids are converted to be hydrophilic phospholipids by adding phosphoric acid to remove oil corners. Then add the alkali solution and let the soap congeals. And it was eventually separated by a disc centrifuge. Finally using vacuum drying and proceed to the next step.

(2) Bleaching:Use active attapulgite clay.Adsorption of fat-soluble pigments, such as carotene and chlorophyll, that affect the color of oils.Improve oil quality and color. After bleaching by active attapulgite clay, the leaf filter will be used to filter out the white soil, to ensure that there is no residual white soil.

(3) Deodorization: The use of more than 200℃ of high temperature evaporation oil odor particles, improve the quality of oil, easy to oil long-term preservation.In this process we use the principles of vacuum and distillation to achieve the highest quality of the oil.

Company Information

Hongde Grain And Oil Machinery Co., Ltd. Group was founded in 1999, is a collection of scientific research, design, manufac-turing, installation, commissioning, after-sales service in one of the high-tech enterprises. We have established long-term strategic cooperation with henan university of technology and zhengzhou COFCO scientific research and design institute to integrate production, learning and research.

We have two manufacturing bases, two special research institutes and three production line installation enterprises, and A1&A2 class pressure vessel design license, manufacturing license and installation qualification. Committed to the research and development of technol-
ogy, equipment and application of grain and oil industry, to provide customers with oil pre-treatment& press machine, solvent extraction plant, oil refinery plant, oil fractionation plant, oil dewaxing and degreasing plant, phospholipid engineering and biodiesel production plant etc.
nearly 20 kinds of production lines.

Insisting on high standard and refinement, zero defect production requirements, precision manufacturing, strictly controlled, we have received more than 60 independent patent property rights, and has passed ISO9001 quality management system certification, CE certifi-
cation, OHSAS18001 certification. Professional oil technical support, on-site guidance of engineering construction and installation,365×24 hours after-sales service, which has won the praise of domestic and foreign customers.

1. Which kind of materials can be processed?
All kinds of oil seeds. For example, rice bran, corn germ, cottonseeds, peanut, sunflower, soybean, rapeseed, etc.

2. Whether the machine price can be more discount?
In general, our MOQ is 1 set with very reasonable price, but if there is a large order, we also can apply to our Manager to appropriately provide you better discount.

3. How long is the delivery time ?

30-90 days varies from different plants and capacities.

4. Is your quote including spare parts ?

Yes, the quote includes one year of spare parts.

5. Besides small oil making machine, what else machines can you do?

We have pressing machines, solvent extraction machines and refinery machines:

Our press/expeller can get cold pressed oil or hot pressed oil from peanut, sunflower seeds, corn germ, cotton seeds, soybean, rapeseeds and other oil crops;
